Marquee Letters

Marquee Letters also called light-up letters or light letters, they are a new type of sign that uses modern LED and PVC ball to simulate traditional light bulb marquee letters. They are merging the nostalgic charm of old marquee signs with the efficiency and durability of LED technology, widely used for business, store, building, storefront, shop, outdoors & indoors.

About Marquee Letters

Sample case

Marquee Letters
  • Marquee letters require a power source so that the LED light source can provide good light. Although solar energy and wind energy are used by more and more users due to their green characteristics, when used as power sources for illuminated signs, these green energy sources need to be matched with energy storage batteries to ensure the stability of the current. Therefore, the stability and cost of this kind of power supply will all be worse than the mains power. Therefore, we recommend using mains power. Whether it is civilian AC or industrial AC, it will be more stable.
  • The vast majority of LEDs are driven by safe 12V DC power. Therefore, if the mains power is used as the power supply, the AC transformer is required to convert the AC power into the 12V DC power required for LED operation. Therefore, it is recommended that before purchasing, you first understand the voltage of the AC power at the place where the marquee letters will be installed, so that we can provide you with a suitable AC transformer.
  • In order to reduce line loss, we recommend that the length of the wire from the signage to the AC transformer be controlled to 3 meters (about 118 inches), otherwise the LED may not fully emit light due to excessive current loss.
  • The AC transformer will generate heat when working, it is recommended that the AC transformer be placed in a place with good heat dissipation. If the AC transformer cannot dissipate heat smoothly, the service life of the transformer will be seriously affected.
  • The installation of marquee letters usually requires drilling holes in the wall, so it is recommended that you confirm with the landlord what restrictions there are on drilling holes before purchasing.
  • Some cities, communities and landlords have certain restrictions on the brightness and color temperature of illuminated signs, so it is recommended that you understand these restrictions before purchasing.

Feature

  • Can be letters, numbers and logo.
  • Each individual part is separate.
  • Using fabricated metal 3D letters shell.
  • LEDs are installed in the letters shell as light source.
  • Drill holes in the front surface of the open face channel and assemble PVC balls. The light is emitted through these exposed PVC balls.
  • Can be used indoors or outdoors.

Tech details

The Min. width of the strokes
1.57"(40mm)
The Min. height of the letters
3.94"(100m)
Default thickness
1.18"(30mm)
Production time
In 15 working days by default
Installation
Flush mounting mostly
  • If you require traditional marquee letters using a light bulb as the light source, please contact us.
  • Can be big letters.

One set of marquee letters consist of the following components:

  • Exposed PVC ball
  • Open face metal letters shell
  • LEDs
  • Cables
  • AC transformer

Exposed PVC ball

Material
PVC

Open face metal letters shell

Material
304/316 stainless steel
Process
Fabrication, laser cutting, laser welding
Default thickness
0.98"(25mm)
Surface finishes
  • Mirror polished stainless steel
  • Brushed stainless steel
  • Angel hair stainless steel
  • Gloss powder coat paints
  • Semi-gloss powder coat paints
  • Matte powder coat paints
  • Mirror polished gold plating
  • Brushed gold plating
  • Angel hair gold plating
  • Mirror polished rose gold plating
  • Brushed rose gold plating
  • Angel hair rose gold plating
  • Mirror polished titanium plating
  • Brushed titanium plating
  • Angel hair titanium plating
  • Mirror polished copper plating
  • Brushed copper plating
  • Angel hair copper plating
  • Mirror polished brass plating
  • Brushed brass plating
  • Angel hair brass plating
  • Mirror polished bronze plating
  • Brushed bronze plating
  • Angel hair bronze plating
  • Vintage copper
  • Vintage brass
  • Vintage bronze
  • Angel hair vintage brass
  • Angel hair vintage copper
  • Angel hair vintage bronze
  • Metallic paint
  • Wood Grain
  • 304 stainless steel fit for most surrounding, 316 stainless steel would be used for the signs in marine environments.
  • The Plating process, vintage process and wood grain process would be finished by our partner, which would cause about an additional 2 working days for the production.
  • The interior of the letter shell is usually white, giving the sign better illumination uniformity.

LEDs

LED type
LED module, LED strip, PCB LED
Lifetime
More than 100,000 hours
Lighting color
  • White (about 6000k color temperature)
  • Warm white (about 4000k color temperature)
  • Red
  • Blue
  • Green
  • Yellow
  • Orange (RGB)
  • Pink (RGB)
  • Purple (RGB)
  • Addressable RGB/RGBW LEDs
  • Using the BlueView brand LED by default. Also have Cree brand LED.
  • For the outdoor signs we will use the water-proof LED lights.

Cables

Type
Plenum copper wire by default
Specification
1.5mm2 (AWG 16) by default
Default Length
60cm (23.62")
  • Suggest using 2.5mm2 (AWG 14) for the trunk wire at least.
  • Trunk wire would not be provided by default.

AC transformer

Brand
Mean Well
Type
waterproof or non-waterproof
Input
110v~240v AC
Output
12v DC
  • The waterproof AC transformers are using MeanWell brand LPV-60V-12 default, IP67, -30~70℃ wide operation range.
  • The Non-waterproof AC transformers are using LRS Series by default, 300VAC input surge, 5G vibration, 70℃ operations.

Installation

Most of the installation methods of marquee letters are flush mount, off-wall mount or raceway mount, using stud bolts to install the signs on the wall.

  • Flush Mount: This installation method uses stud bolts and is installed separately on the building facade using the mounting holes. The wires used to power the lighting are fished out of the wire holes and mounted behind the wall so light source maintenance can be easily done from behind. Typically, each individual illuminated sign part has 2-3 stud bolts and 1 wire, so 3-4 holes need to be drilled in the wall for this. Obviously, this installation method will increase the installation workload, but since the wires and stud bolts are buried in the wall, the installed signs will be sleek and sophisticated.
  • Off-wall Mount: The only difference between this installation method and flush mount is that the sign is away from the backing wall, and spacers are used to ensure that each part is at the same distance from the wall.
  • Raceway Mount: In this installation method, the sign is first mounted on a slender metal mounting structure called a "raceway", usually made of aluminum or stainless steel, and then the raceway and signs are mounted on the wall as a whole. The interior of these mounting structures can be used to house electrical wiring and AC transformers. The advantage of this type of installation method is that it has fewer holes need to be drilled, which can be an important consideration for building owners or landlords, and it also makes it easier to install and renew the signage, while creating an off-wall visual for the sign, so the three-dimensionality will be better. However, due to the existence of the "raceway", the integrity of the sign and installation wall will be weakened.

To ensure your signage is installed correctly for optimal display and longevity, we recommend hiring professional installers. We will provide a 1:1 layout template to show the hole positions of stud bolts and wires, the installer will drill holes on the wall according to these hole positions. If it is an illuminated sign, the wiring work of the wires needs to be completed. We will provide installation instructions, wiring diagram and necessary installation accessories to help your installers complete the installation correctly and quickly. If you are unable to find the professional installers, please let us know and we will put you in touch with one of our partners to find good installers for you.

Others

Certificate
CE, UL, ROHS
Recommended working temperature
-20℃ ~ +65℃ (-4℉ ~ +149℉)
Default IP rating for outdoor use
IP65
Warranty
Three Years
Accessories
  • stud bolts
  • nuts
  • washers
  • tube spacers
  • 1:1 layout template
  • wiring diagram
  • installation diagram
  • The recommended working temperature means that based on our experience, the sign can keep working within this temperature range for a long time without significantly reducing the service life. Generally speaking, illuminated LED signs can work in a wider temperature range, usually -30℃ ~ +70℃ (-22℉ ~ +158℉) but the harsher environment will shorten the service life of the signs.
  • Stud bolts are necessary for installation, used to fix the signs on the backing wall.
  • Nuts and washers are only fit for situations where people can work at the other side of the backing wall, then can use washers and nuts to secure the stud bolts to the wall.
  • If you need the marquee letters off the backing wall, we will provide the stainless steel tube spacers with 20mm (0.8") length by default, electrical wiring and stud bolts can through the tube spacers, used to make all the individual part of the marquee letters have the same distance between the backing wall.

Warranty

  • In three years, if it is not the man-included damage, we will send you the damage part.
  • After 2 years, because of the half-life, the LED lighting would be weaker. In order to keep the effect of the signs, we suggest changing the LED lights when you feel the brightness could not reach your requirement.
